You're almost there.

Your payment was received. Before we place your order with Atlas, we just need a few quick details. This takes most people about 5 minutes.

A Western Stairlifts team member will call you within 1 business day to confirm everything before your unit ships.

Contact Details

We'll use this to reach you for the confirmation call.

Stair Measurements

Use the diagram below as a guide. Approximate is fine — we'll verify on your call.

Stair Measurement Reference — measure in inches

Staircase measurement diagram
1
Overall LengthExtend your tape measure along the full diagonal run of the staircase, from the bottom landing to the top step. This is the longest measurement and captures the complete travel distance of the lift.
2
Staircase WidthMeasure straight across the width of your stairs at the base. This confirms the lift will fit within your staircase without obstruction.
3
Bottom ClearanceIf there is a wall, door, or obstruction at the foot of the stairs, measure from the bottom step out to that surface. This ensures the lift can safely complete its descent.
4
Rise of One StepMeasure vertically from the top surface of one step down to the top surface of the next. This is the height of a single step.
5
Tread DepthMeasure horizontally from the front edge of one step to the front edge of the step directly behind it. This tells us how deep each individual step is.
6
Top ClearanceMeasure from the top step to any wall, door, or overhead obstruction at the top of the staircase. This ensures the lift can park safely at the top without interference.

Stand at the top and extend a tape measure down so it lays along all the treads, tip touching the bottom landing.

inches

Width of the staircase measured wall to wall (or wall to banister).

inches

Distance from the bottom riser to the nearest wall, door, or obstruction at the base of the stairs.

inches

Vertical height of a single step — from the top of one tread to the top of the next.

inches

Horizontal depth of a single step — from the front edge to the back edge of the tread.

inches

Distance from the top riser to the nearest door, wall, or obstruction at the top of the stairs.

inches

Installation Details

Which side of the staircase should the track mount on, when you stand at the bottom and look up?

Power note: If you don't have a 110V outlet within 6 feet of the top or bottom landing, you'll need to have one installed or use an extension cord. We'll go over this on your confirmation call.

Photos of Your StaircaseStrongly recommended

Photos help us confirm the fit and reduce back-and-forth before your call.

1

Bottom looking up — stand at the bottom step and photograph the full staircase going up

2

Top looking down — stand at the top landing and photograph looking down the stairs

3

Full side view — step to the side of the staircase to show the complete profile

Click to upload or drag photos here

JPG, PNG, HEIC accepted · Multiple files OK

Loading security check...

This helps us prevent automated submissions. Please complete the security check above to continue.

You'll receive a copy of this submission by email. We'll call you at the number provided within 1 business day.

After You Submit

What Happens Next

01

We review & call you

A team member reviews your submission and calls at your preferred time to confirm measurements and placement.

02

We place the order with Atlas

Once everything checks out, we place your confirmed order directly with Atlas Mobility.

03

Atlas ships to your door

Your unit ships freight directly from Atlas. The Atlas 500 typically arrives within 7 days of ordering.

Questions before your call? Call us at 801-386-2408
